SNG (gas-silicon) is a high-barrier film developed for gas-silicon vacuum insulation panels. It has excellent anti-aging, oxygen and water resistance properties. The porous structure of the gas-silicon film has a strong adsorption effect on water vapor and is resistant to external pressure With low sensitivity and longer lifespan, it is suitable for scenes requiring long lifespan, such as construction.
| product name | unit | SNG (gas-silicon) Fumed Silica Film | test method |
| thickness | μm | 93 | GB/T6672 |
| width | mm | 200-1100 | GB/T21302 |
| Puncture strength | N | 21 | GB/T21302 |
| Total solvent residue | mg/㎡ | ＜5 | BS6455:1984 |
| Helium transmission rate | mbar·L/(S·㎡) | 5*10-8 | Intrinsic benchmark |
| water vapor transmission rate | g/㎡·24hr | ＜0.01 | GB1037 |
| Oxygen transmission rate | cc/㎡·d | ＜0.1 | GB/T31354 |
| seal strength | N/15mm | ＞60 | QB/T2358 |
| High and low temperature aging 80℃→-30℃reciprocating cycle for 28 days，65%RH | △k=mW/(m·k) | ≤1.0 | GB/T39548 |
| High temperature and high humidity aging 70℃，90%RH aging for 30 days | △k=mW/(m·k) | ≤2 | GB/T39548 |
| features | / | cost-effective, | / |
| The performance is fully ahead of the foreign products of the same model |
